nPFocus1000

Long-travel piezo Z focus stage

nPFocus1000 Nanopositioning Piezo Stage

Long travel objective scanner with 1000μm travel range.

Request Quote

Long travel objective scanner with 1000μm travel range.

Part Number3715250
Footprint64.54mm W x 77mm D x 40mm H
MaterialAluminum/SS
Maximum Load0.8kg
Max Force (Push/Pull)20N/10N
Stage Mass490g
Nanomotion ControlZ
Closed-loop Travel1000µm
Open-loop Travel (-30 to 150 V)1150µm
Position Noise5nm
Stiffness0.1N/µm
Resonant Frequency135Hz
Settling Time25ms
Linearity Deviation0.02%
Capacitance17.8µF
Integrated SensorCapacitive
Cable Length2m
ControllerLC.400
